OPC server allow data exchange via Modbus
|
Modbus OPC server 2.3
Author:
Supported languages: English
Supported OS: Win2000 / WinXP / Win7 x32 / Win7 x64 / Windows 8 / Windows 10 / WinServer / WinOther / WinVista / WinVista x64
Price: $280.00
|
|
|
|
|
|
The OPC server provides the OPC clients (any advanced SCADA systems) with an access to devices, supporting the MODBUS protocol.
To have a trial run of the software product, you can use, absolutely free of charge, 30 tags without any time limit. To handle more than 30 tags, you can use a 30-day fully functional trial period.
Key functions
Supported protocols: MODBUS RTU, MODBUS TCP, MODBUS ASCII
Supported MODBUS functions: 1,2,3,4,5,6,15,16
Supported communication channels: COM port, TCP connection
Opportunity to use an extended list of communication channel types (CSD, GPRS, etc.), using the Modem Communication Channel Module special software
Opportunity to poll tag groups of the device at varying intervals
Interaction with the OPC clients in accordance with the OPC DA specifications, version 2.05a
Service operation function (Windows OS Service)
Group setting of tags
Configuration import/export in the CSV format (with a report file formatting)
Ability to survey and view tag values without the OPC client connection
Ability to operate at a broadcast address
Ability to emulate tag values
OPC server operation logging.
Features
Automatic search for connected devices reduces the configuring time.
Configuration import/export into the CSV format significantly accelerates the configuring process.
Polling tag values of the device at varying intervals increases the speed of reading of critical parameters.
Surveying and viewing tag values without the OPC client connection allows the OPC server to be initially set without application of any additional software.
Tag value emulation provides the opportunity to debug projects in the upper level systems without any physical access to metering instruments.
|
Free Modbus OPC server download - 7.54 MbMODBUS_v2_3.zip
|
